Then the magic begins. 18-gauge copper wire stitches
                              are used at approximately 50mm centres by threading
                              the wire through predrilled small holes thus, stitching
                              the edges together, first loosely until the edges are
                              perfectly together and then tightly by twisting the
                              copper wire using pliers. Thus, the chines are formed. To
                              control the shape, the planks are similarly stitched to the
                              moulds. An alternative to copper wire is to use thin cable
                              ties, but they require slightly bigger predrilled holes and
                              once the cable ties are tied, they cannot then be
                              loosened only tightened which is no good.

     Step 6 is to spot weld the edges together using a Cyanoacrylate glue commonly
     known as ‘superglue’ with glue spots at approximately 40mm. centres. Once the glue
     has cured in around 10 seconds, the copper wire
     stitches are removed and a fillet of thickened epoxy
     with the consistency of peanut butter, is applied to
     the inside of the spot-welded planks. Wiping a neat
     even fillet of thickened epoxy is tricky. After a few
     mishaps, I eventually hit on an efficient process which
     is to first stick lengths of low tack masking tape
     around 15mm from each edge, thus controlling the
     spread of the fillet. After removing the tape, the next
     step is to smooth off the fillet and to run a length of
     fibreglass tape along the seam which is wetted
     though with unthickened epoxy. The entire joining
     process from copper stitching to taping is shown in an
     illustrative mockup I made.

     Step 7 is repeat this process for the top half of the shell. The two halves are stiffened
     in appropriate positions with seven bulkheads or stiffeners.
